Screw Air Compressor- Direct coupling type CWD110KW/150HP A/W

FOB Reference Price:Get Latest Price
US $3,000-50,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Screw
Configuration:
Stationary
Power Source:
AC Power
Lubrication Style:
Lubricated
Mute:
Yes
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
CROWNWELL
Model Number:
CWD110KW/150HP A/W
Voltage:
380V(It can be made by customer's requirement)
Dimension(L*W*H):
2300*1600*1790
Weight:
2800KGS
Certification:
CE;GC;IAF;ISO9001:2000
Warranty:
2
After-sales Service Provided:
Engineers available to service machinery overseas
Color:
Gray (our Standard)
Packaging & Delivery
Packaging Details
Standard Seaworthy
Port
Shanghai
Lead Time :
About 20 days, confirmed by order



Crownwell offer a range of robust industrial rotary screw air compressors with pressure from 7 to 13bar and power from 7.5 to 400KW. Like all Crownwell compressors, Panther is backed-up by a group of senior engineers with more than thirty years design experience. Crownwell offers the industries most reliable and cost competitive compressed air packages. Each component has been thoroughly evaluated for its reliability and high-efficiency and optimized for easy maintenance.


Rotor is the key element in producing compressed air efficiently. Crownwell airends utilize a 5-lobe male rotor (driving rotor) and a 6-lobe female rotor (driven rotor) which are the top class and new generation. Crownwell core guarantees you superior FAD efficiency, more robustness and reliability.

Larger rotors are designed to ensure slower rotor speed of airends to deliver compressed air more efficiently than small airends. It contributes to energy cost savings and a longer lifespan. Oversized SKF bearings and triple discharge end bearing design offers long operating life.


IP54 high-efficiency IEC motors are adopted. Over sized cast iron conduit boxes make connections easy. The best grease is used to protect the SKF bearings. High performance and low temperature rise. The lastest Germany designed spider couplings are used to guarantee the reliability and driving efficiency and provide vibration free power driving for quiet and maintenance free operation.

Suction valve is the major air flow control component. It controls air flow to the compressor either by opening, throttling, or closing completely in response to pressure sensor controls. High quality& high reliability.

The three-stage separation system supplies high quality compressed air. Oil separator adopts tangential intake, there is a oil baffle between inner wall and apron to pre filter lubricant, then the oil-air mixture flow out through oil separator from inside to outside. The separation tank has two different separation stages: centrifugal and gravity. The third stage separation is provided by a high performance, long life coalescent separator filter. The efficiency of the first two stages assures the long lifespan of this coalescent filter. This system limits oil vapors carryover to below 3ppm.

Featured with large filtering covering and high preciseness. It effectively filters the remains of the worn flying parts and the impurities in the oil, which makes lubricant circularly injected into rotor and bearing filtered clean, and guarantees much longer lifespan of the compressor.

99.99% high efficiency, low pressure loss, Germany imported air filter provides filtration to less than 3microns utilizing ultra web nanofiber technology which ensures clean, unrestricted air flow for optimal compressor operation. It controls the suction air quality and guarantee the compressor can work in a heavy dust and complex working environment.

Full control in a few clicks. Crownwell LCD controller gives you easy access to menus and all key performance indicators necessary to drive your operation. It also features remote control interface with up to 4 compressors,programmed routine maintenance, fault log , recording of running history, warning and stop alarms, and several other functions. All microprocessor functions are password protected, accessible only by authorized personnel.

Famous Schneider electrical components are adopted which has long lifespan and strong capability of shock resistance, to avoid damage when voltage is unstable.

Stationary Rotary Screw Compressors-Stable, Reliable, High-efficiency
